Compression Plates, 50 kN Force Capacity

496.00
        SPECIAL OFFER

          Please select all product options

          Product was out of stock

          share
          Description

          Compression plates ranging from 56mm to 246mm with a maximum load capacity of 50 kN feature concentric rings for precise sample placement.

          Adapters are available to mount platens to almost any test stand.

          • Load Capacity: 50 kN (4,500 lbF)
          • Material: Hardened steel 58 HRC, nickel-plated
          • Connection (Coupling): 1.25' (31.8 mm) Female eye end
          • Scope of delivery:
            • 1 Compression plate
            • 1 Clevis pin
          Dimensions
          Model
          		Diameter (A) Weight
          mm inches kg lbs
          CP156-ST-318 156 6.14 2.03 4.47
          CP196-ST-318 196 7.72 3.3 7.26
          CP246-ST-318 246 9.69 7.77 17.09



          Dimensional drawing for compression plate
              Eye End Coupling (B from above) Dimensions - mm
                • Connection (Coupling): 1.25' (31.8 mm) Female eye end
